CABLE LENGTH
| ATX Cable | 1x 600mm (m) |
| EPS Cable | 2x 700mm (m) |
| PCIe Cable | 3x 700mm, 850mm ; 2x 700mm |
| SATA Cable | 3x 550mm, 650mm, 750mm, 850mm (m) |
| Four-Pin Peripheral Cable | 1x 550mm, 650mm, 750mm, 850mm (m) |
| Floppy Adapter | 1x 100mm |
| AC Power | 1x 1500mm (m) |
| Modular Cable Type | Full |
CONNECTOR QUANTITY
| 24 Pin ATX | 1x 24pin |
| EPS (CPU) | 2x 8pin (4+4) |
| PCIe | 8x 8pin (6+2) |
| SATA | 12x |
| Four-Pin Peripheral | 4x |
| Floppy | 1x |
INPUT
| Input Voltage | 100-240V~ |
| AC Input | 15-8A |
| Input Frequency Range | 60/50 Hz |
| Efficiency | 92% (115VAC) / 94% (220VAC~240VAC) or Higher Typical |
OUTPUT
| Rail | +3.3V | +5V | +12V | -12V | +5Vsb |
| Max output | 24A | 24A | 83.3A | 0.5A | 3A |
| 120W | 999.6W | 6W | 15W | ||
| Total | 1000W @ +50C | ||||
ADDITIONAL DETAILS
| Operating Temperature | 0° to 50° C |
| Japanese Capacitors | 100% |
| ECO Mode | Yes |
| MTBF | 100,000 Hours |
| Gross Weight | 7 lbs |
| Size | 86mm (H) x 150mm (W) x 150mm (L) |
| Approvals | TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS Compliance with ErP Lot 3 2014 Requirement |
| Fan Size / Bearing | 135mm Fluid Dynamic Bearing |
| UPC | 843368067892 |
| EAN | 4250812438898 |
